Carbon Gravel/CX Wheels

WE CURRENTLY ARE ABOUT 5 WEEKS OUT ON OUR ROL HUB BUILDS FOR OUR C35AR WHEELS.

HAND BUILT IN DENVER COLORADO

WE WILL CONFIRM AN APPROXIMATE DELIVERY DATE WHEN THE WHEELS ARE ORDERED. THE APPROXIMATE TIME FOR WHEEL BUILDS WITH WHITE INDUSTRIES IS APPROXIMATELY 5 WEEKS.

OVERVIEW

The C35AR is a lightweight, fast and comfortable precision tool for the serious adventurer.  It is our Adventure Road model, and is comfortable on any road, paved or gravel.

The shallower 35mm rim profile handles confidently in cross-winds, while their momentum carries speed well.  The greatest single contributor to the design of our new rim profiles is the blunt, "bullnose" shape of its "spoke face".  Designed using CFD (Computational Fluid Dynamics), we labored to create a profile that would slice through the air at any yaw angle while increasing crosswind stability.  Our 21mm internal width of the rim provides a better fit for higher volume tires that increase grip, lower rolling resistance and provide greater comfort.

CARBON RIM SPECS

Material: Toray T700

Internal Width: 21mm from bead to bead - 24mm sidewall to sidewall

External Width: 28mm (30mm Max)

Depth: 35mm

Recommended Tire Widths: 25mm to 45mm

Spoke Count 24/24

Rider Weight Limit: 260 lbs

Max Tire Pressure: 110lbs

Premium bladed SAPIM spokes and locking nipples yield a durable and reliable wheel set for years to come.  We lace them to our very own ROL CLD Hubs featuring the highest-rated ABEC-5 stainless steel bearings. We can accommodate most freehub combinations (email us if you need something not listed).

FREEHUBS: Shimano HG, Shimano MicroSpline, SRAM XDR, Camapgnolo, Campagnolo N3W

Disc brake axle types are as follows:

Front
Quick Release
12mm thru-axle
15mm thru-axle (Please indicate at checkout if you need 15mm End Caps)

Rear
Quick Release
12mm x 142mm thru-axle

CUSTOM OPTIONS

We offer several custom options, such as spokes, hubs and hub colors. please feel free to email tom@rolwheels.com if you are interested in an option not available on the website.


SPECS

• 35mm ROL Proprietary Full Carbon Clincher Rim
• 21mm Internal Rim Width - Tubeless Compatible
• 30mm Max Width
• ROL 3-D Forged Hubset (White Industries, Onyx and Chris King also avialible)
• Shimano HG, Shimano MS, SRAM XDR, Campagnolo and Campagnolo N3W freehubs

• SAPIM Bladed J-Bend Spokes - Black
• Locking Nipples (Brass for durability)
• 24 Spoke Front - 2 cross lacing
• 24 Spoke Rear - 2 cross lacing
• ABEC 5 TPI Steel Sealed Cartridge Bearings
• ROL Rim strip or tubeless tape included
• The rims will come with either black decals or a grey etched logo

WE ARE CURRENTLY 5 WEEKS OUT ON OUR BUILDS WITH ROL HUBS.

HAND BUILT IN DENVER COLORADO

FOR ORDERS WITH UPGRADED WHITE INDUSTRIES, ONYX OR CHRIS KING HUBS, THE DELIVERY DATE IS APPROXIMATELY THE SAME LENGTH OF TIME  WE WILL CONFIRM AN APPROXIMATE DELIVERY DATE WHEN THE WHEELS ARE ORDERED.

OVERVIEW

The C45AR is a lightweight, fast and comfortable precision tool for the serious adventurer.  It is our Adventure Road model, and is comfortable on any road, paved or gravel.

For criteriums, triathlons, flat-to-rolling road races and even cyclocross, our all-carbon clincher wheelset is fast, light and comfortable. The C45 uses a deeper-depth rim: it's light enough to accelerate and climb, while its aerodynamics make you feel like you have an added gear at race speeds..  The greatest single contributor to the design of our new rim profiles is the blunt, "bullnose" shape of its "spoke face".  Designed using CFD (Computational Fluid Dynamics), we labored to create a profile that would slice through the air at any yaw angle while increasing crosswind stability.  Our 21mm internal width of the rim provides a better fit for higher volume tires that increase grip, lower rolling resistance and provide greater comfort.

CARBON RIM SPECS

Material: Toray T700

Internal Width: 21mm from bead to bead - 24mm sidewall to sidewall

External Width: 28mm (30mm Max)

Depth: 45mm

Recommended Tire Widths: 25mm to 45mm

Spoke Count 24/24

Rider Weight Limit: 260 lbs

Max Tire Pressure: 110lbs

Premium bladed SAPIM spokes and locking nipples yield a durable and reliable wheel set for years to come.  We lace them to our very own ROL CLD Hubs featuring the highest-rated ABEC-5 stainless steel bearings. We can accommodate most freehub combinations (email us if you need something not listed).

FREEHUBS: Shimano HG, Shimano MicroSpline, SRAM XDR, Camapgnolo, Campagnolo N3W

Disc brake axle types are as follows:

Front
Quick Release
12mm thru-axle
15mm thru-axle (Please indicate at checkout if you need 15mm End Caps)

Rear
Quick Release
12mm x 142mm thru-axle

CUSTOM OPTIONS

We offer several custom options, such as spokes, hubs and hub colors. please feel free to email tom@rolwheels.com if you are interested in an option not available on the website.


SPECS

• 45mm ROL Proprietary Full Carbon Clincher Rim
• 21mm Internal Rim Width - Tubeless Compatible
• 30mm Max Width
• ROL 3-D Forged Hubset (White Industries, Onyx and Chris King also avialible)
• Shimano HG, Shimano MS, SRAM XDR, Campagnolo and Campagnolo N3W freehubs

• SAPIM Bladed J-Bend Spokes - Black
• Locking Nipples (Brass for durability)
• 24 Spoke Front - 2 cross lacing
• 24 Spoke Rear - 2 cross lacing
• ABEC 5 TPI Steel Sealed Cartridge Bearings
• ROL Rim strip or tubeless tape included
• The rims will come with either black decals or a grey etched logo

WE ARE EXCITED TO OFFER OUR C45 CARBON WHEELS IN A MORE ROBUST CONFIGURATION FOR HEAVIER RIDERS. THE WHEELS ARE AVAILABLE WITH EITHER ROL OR WHITE INDUSTRY HUBS. PLEASE ALLOW A 5-6 WEEK LEAD TIME AS WE CUSTOM BUILD THE RIM TO THE CUSTOMER. THEY ARE AVALIABLE WITH SHIMANO HG, SRAM XDR AND CAMPAGNOLO FREEHUBS.

HAND BUILT IN DENVER COLORADO

FOR CHRIS KING OR ONYX HUBS, PLEASE REACH OUT TO TOM@ROLWHEELS.COM FOR PRICING. HUBS WILL BE BLACK, UNLESS OTHERWISE SPECIFIED. IF YOU WANT A COLOR FOR HUB, PLEASE SEND A MESSAGE TO TOM@ROLWHEELS.COM.

OVERVIEW

This is a great all-around wheel for all types of riding. The C45's have been popular for road riding and racing, time trials and triathlons, gravel and cyclocross. This carbon wheelset is fast, strong and comfortable. The C45 uses a mid-depth rim: it's light enough to accelerate and climb and a joy in cross winds, while its aerodynamics make you feel like you have an added gear at race speeds.

The C45 measures 28mm at its widest point - a bit wider than most to improve the tire's aerodynamics and widen its contact patch for better handling. You'll get more out of your chosen tires with a wider rim.

Premium Sapim Race Spokes are double butted and provide a combination of lighweight and strength.  The brass Sapim Secure Lock nipples work great for strength and hold up better to corrosion than standard alloy nipples.

The C45 can be built with a number of different axle combinations. If you don't see it, let us know and we will get you taken care of. Disc brake axle types are as follows:

Front
Quick Release
12mm thru-axle
15mm thru-axle

Rear
Quick Release
12mm x 142mm thru-axle

SRAM XDR and Campagnolo free hubs are available with the ROL and White Industries hubs.

SPECS

• 45mm ROL Proprietary Full Carbon Clincher Rim
• Hook Bead
• Maximum Weight - 287 pounds
• 21mm Internal Rim Width - Tubeless Compatible
• 30mm Max Width
• SAPIM Double Butted J-Bend Spokes - Black
• SAPIM SecureLock Nipples
• 28 Spoke Front - 2 Cross
• 28 Spoke Rear - 2 Cross
• Max tire pressure - 110 lbs (tubes)
• Recommended tire widths - 23c to 43c
• Black decals or etched grey logos

WE HAVE A LIMITED NUMBER OF ROL HUB WHEELSETS AVAILABLE - ORDER YOURS TODAY. SINCE WE BUILD OUR RIMS TO ORDER, PLEASE ALLOW ABOUT A 5 TO 6 WEEK LEAD TIME.

UPGRADES TO WHITE INDUSTRIES, ONYX OR INDUSTRY NINE HUBS ARE AVAILABLE.

HAND BUILT IN DENVER COLORADO

The Range Disc Carbon Clincher is one of the lightest and strongest carbon tubeless disc wheelsets on the planet.

OVERVIEW

Built with our proprietary Gravel/CX rim utilizing unidirectional Toray carbon fiber pre-preg, our rim comes in at a scant 353 grams! Laced to a ROL CLD Hub, or an upgrade to either a White Industries CLD or Industry Nine hubset, with SAPIM blade spokes and locking nipples, the Range Carbon is a phenomenal blend of light weight, stiffness, precise handling and exceptionally user-friendly tire mounting.

INDUSDRY NINE HUBS

Bringing the proven technology from I9's 1/1 mountain hubs, 1/1 road offers a reliable hub platform that stays true to the performance heritage known from I9 in a budget friendly package. A direct descendent from the mountain life, the 1/1 hubs are engineered with high capacity bearings, ready for anything the road or trail can throw at them. Constructed with a dual phased-pawl drive mechanism with 90 points of engagement or 4° between engagement, the hubs offer rapid power transfer for rocketing out of corners or ratcheting through uneven terrain. Utilizing the same construction as I9's 1/1 mountain bike hubs, the 1/1 gravel line is perfect for any route that involves gated off forest service roads, bikepacking or bomb proof road builds.

Both Industry Nine and White Industries hubs are American made. Every wheelset is hand built to perfection in Colorado. This gravel wheelset comes in any axle configuration.

SPECS

• 25mm Deep, Hooked Carbon Tubeless Rim
• 24mm Internal Width  30mm External Width
• American made hub options from Industry Nine or White Industries
• SAPIM Blade Spokes
• SAPIM Secure Lock Nipples
• 28 spoke Front - 2 Cross
• 28 spoke Rear - 2 Cross
• Tubeless Compatible
• Wheelset Weight:  1,410g



• Recommended rider weight limit is 225lbs.
